Blueprint to CAD construction

Blueprints of mechanical parts, architectures or site plans are merely paper drawings and subjected to wear and tear and fade away with time. These blueprints can be preserved or digitized with the help of handheld 3D scanners and reverse engineering software like Geomagic Design X. Remodeling becomes easy in Geomagic Design X, and presentation is enhanced with layers and color coding. We can move the elements of the 2D drawing dynamically into positions suitable for converting them into 3D views. This process reduces or completely eliminates the needs and costs of valuable space used for storing paper blueprints. These digitized CAD files can be given as neutral files for data exchange.
