EINSCAN - SE

A powerful companion for educators and individuals

BOOK A DEMO GET A QUOTE NOW
3d-laser-scanner-services-Einscan-SE

The EINSCAN-SE is mainly geared towards education.The Automated software provides plenty of capability for the user to scan and generate a CAD model for Printing. There is no need for further design or data preparation.

KEY FEATURES

3d-laser-scanner-services-Einscan-SE
Safety in use

Visible white light and no laser. Safe and secure for scanning of children.

3d-laser-scanner-services-Einscan-SE
Fine details

Every scan generates high-quality 3D data. Reconstruction of real geometry of the object with fine details.

3d-laser-scanner-services-Einscan-SE
Easy Operation, User-friendliness, and faster scanning
  • One-click scanning
  • Automatic calibration with no rigid set-up required
  • 8 seconds for a single scan
  • 2 minutes for a 360-degree scan under Auto Scan mode
3d-laser-scanner-services-Einscan-SE
Compatible with 3D printers
  • Auto meshing to watertight 3D data
  • Seamlessly connect to 3D printers
  • Provide API access service for any branded 3D printer
3d-laser-scanner-services-Einscan-SE
Extensive post-processing functions

Software of EinScan-SE/SP has the functions of filling holes, smoothing, sharpening, and can also readjust the data coordinates in the post-processing process to provide perfectly organized 3D data for subsequent applications.

SPECIFICATIONS

<

Scan Mode

Fixed Scan

Auto Scan

Mode of Alignment Feature; Manual Turntable; Manual
Single Shot Accuracy ≤0.1 mm
Minimum Scan Volume 30 × 30 × 30 mm
Maximum Scan Volume 700×700×700 mm 200×200×200 mm
Range of Single Capture 200×150 mm
Scan Speed < 8 s
Point Distance 0.17 mm ~ 0.2 mm
Texture Yes
File Format OBJ, STL, ASC, PLY
Camera Resolution 1.3 Mega Pixels
Light Source White Light
Stand-off Distance 290 ~ 480 mm
Computer Requirements (Required) USB:1 ×USB 2.0 or 3.0; OS: Win7, Win8, Win10 (64 bit); CPU: Dual-core i5 ; RAM: 8G
Computer Requirements (Recommended)Graphics card: Nvidia series;Graphics memory > 1G
Weight (packed) 4.9 kg
Dimension 570×210×210 mm
Power Supply 40 w
Input Voltage DC:12 v, 3.33 A
Calibration Board Standard
Turntable Standard
Load Capacity of Turntable 5 kg

DEMO VIDEO

EINSCAN - SE

EinScan Desktop 3D Scanner

EinScan - SE

EinScan-SE 3D Scanner Setup Tutorial

SAMPLE DATA

3D OBJECT VIEWER

Frequently asked questions

What are all the object sizes can you scan in EinScan SE?

EinScan SE is a desktop Scanner used by education and individuals for Scanning small parts maximum weight of 5 kg in which the turntable can hold and size lesser than the coded targets inside the turntable.

Einscan SE uses Structured white light Scanning technology.

It's not advisable to use EinScan SE in daylight conditions. Scanning in daylight conditions may result in excessive exposure to light. It affects the Scanner's accuracy and creates lots of noise while scanning due to the scattering of light over the object to be Scanned.

NO, we cannot do the color scan in EinScan SE.
