APPLICATIONS

. High definition master patterns for making silicone or RTV molds especially for high volume, mass production of jewelry designs

. Jewelry design and functional prototyping

. Snap-fit and stone-in-place testing

. Client fit/try-on models

BENEFITS

. Compatible with a range of silicones

. No silicone inhibition

. High visualization

. Safe for extended try-on testing and user fittings

. Jewelry-specific build styles

. MicroPointTM support tips minimizing support to- part interaction and support scarring

FEATURES

. High heat deflection temperature

. Exceptional surface finish and fine details definition

Fast speed:

- Prototyping speed – 45 mm/hr @ 50μm Z resolution

- Master pattern speed – 15 mm/hr @ 30μm Z resolution

. High contrast gray color

. Fast throughput to finished part; no secondary thermal cure required

. Passes biocompatibility standard ISO 10933-5 for cytotoxicity

TECHNICAL SPECIFICATIONS

KEY MECHANICAL PROPERTIES

. Elongation at break: 2.5%

. Tensile modulus: 3500 MPa

. Tensile strength: 67 MPa

. Heat deflection temperature: >300 °C @ 0.455 MPa/66PSI
